Spirally Submerged Arc Welding Pipe (SSAW)

API 5L PLS1,PLS2

Description:

SSAW pipe is a kind of spiral seam steel pipe, which is made of strip and coil as raw material, often extruded and formed

by automatic double wire submerged arc welding.

Size:

OD:219mm - 2032mm,Thk: 5-22mm

Standard:

API SPEC 5L,5CT,ASTM A53,BS1387,GB/T9711,ISO3183

Grade:

Q235A，Q235B、10#、20#、Q345（16Mn）、L245(B)、L290（X42）、L320（X46）、L360（X52）、L390(X56)、L415(X60)、

L450(X65)、L485(X70)、L555(X80)、L290NB/MB（X42N/M）、L360NB/MB（X52N/M）、L390NB/MB(X56N/M)、

L415NB/MB(X60N/M)、L450MB(X65)、L485MB(X70)、L555MB(X80)

Usage:

mainly used in water supply engineering, petrochemical industry, chemical industry, power industry, agricultural irrigation, urban construction

For liquid delivery:

Water supply, drainage, petroleum transportation.

For gas transportation:

Gas, steam, liquefied petroleum gas, natural gas.

For structural purposes:

 piling pipes, bridges, piers, roads, building structures, pipes and so on.

Coating:

blue epoxy resin, single/double epoxy powder,black/blue 3PE,IPN8710 polymer coating,coal tar epoxy coating,cement mortar lining,polyproylene 3PP,preformed direily,buried polyurethane,steel lining FBE,GZ-2 polymer coating

Packing:

Bare or as customer required
